MRCOOL Signature 24K BTU Single Phase Packaged Heat Pump MPH241M414A
MRCOOL Signature 24K BTU 14 SEER Multi-Position Packaged Heat Pump MPH241M414A
This product is no longer available, Our sales professionals can help you in finding something similar that matches your style, space, and budget. Feel free to contact us today at +1-800-583-0045 or email us at [email protected]
The MRCOOL Signature 24K BTU 14 SEER Multi-Position Packaged Heat Pump MPH241M414A is an excellent choice due to its high efficiency and versatile installation options. With a SEER rating of 14, it offers cost-effective cooling and heating solutions while reducing energy consumption. Its multi-position design allows for flexible installation in various configurations, making it suitable for different spaces. This model ensures reliable performance and comfort throughout the year, enhancing your home's HVAC system.
Features:
- Warranty is 10 years on all parts if registered, 5 years if not (no licensed tech required)
- 14 SEER efficiency
- Designed for easy and convenient installation
- Optional electric heat available
- R-410A environmentally friendly refrigerant
- Built in short cycle protection to protect the compressor
- One piece "no leak" top design
- Sloped drain for improved indoor air quality
- Louvered panel coil protection
- Insulation to minimize heat loss plus reduce sound
- Built in "quiet shift" operation during defrost on select models
- Efficient constant torque motor for wide airflow range
Manuals
Manuals:
Specifications
Specifications:
| Product Dimensions | 46.8"W x 46.77"D x 36.82"H |
| Product Weight | 315 lbs |
| Unit Type | Packaged Heat Pump |
| SEER | 14 |
| EER | 11 |
| COP 47 | 3.7 |
| HSPF | 8 |
| CFM | 845 |
| Tonnage | 2 |
| Cooling Capacity | 22,600 |
| Heating Capacity | 22,000 |
| Voltage | Requires a minimum of 208V-230V/60HZ/25A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 |
| Stage | Single |
| Max Fuse Breaker | 25 |
| Min Circuit Ampacity | 17.4 |
| Color | Gray |
| Rated Load | 12.1 |
| Max Coverage Area | 1,000 |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 91 |
| Decibel Rating | 78 |
| Min Ambient Heat | 0 |
| Compressor Motor Type | Scroll |
| Condenser Fan Motor Type | ECM |
| Condenser Fan Motor HP | 1/6 |
| Blower Motor Type | ECM |
| Blower Motor HP | 1/3 |
| Blower Motor Speeds | Multi-Speed |
| Blower Motor RPM | 380-840 |
| Filter Type | Replaceable |
| Filter Size | 14x20x1 |
| Metering Device | TXV |
| Auxiliary Heater | Yes |
| Auxiliary Heater Sizes | 5kw |
| Certifications | ETL AHRI |
| Warranty | Warranty is 10 years on all parts if registered |
| Base Warranty | 5 years if not (no licensed tech required) |
