MRCOOL GeoCool 24K BTU 2 Ton Vertical Heat Pump with Desuperheater GCHPV024TGTANDR
MRCOOL GeoCool 24K BTU, 2 Ton, Vertical Two-Stage Right Return Geothermal Heat Pump with Desuperheater GCHPV024TGTANDR
Why is the MRCOOL GeoCool 24K BTU, 2 Ton, Vertical Two-Stage Right Return Geothermal Heat Pump with Desuperheater GCHPV024TGTANDR a top choice for energy-efficient and eco-friendly residential climate control?
The MRCOOL GeoCool 24K BTU, 2 Ton, Vertical Two-Stage Right Return Geothermal Heat Pump with Desuperheater GCHPV024TGTANDR is a top choice for energy-efficient and eco-friendly residential climate control. With a 24K BTU capacity and two-stage operation, it delivers precise and reliable temperature regulation. The vertical design with a right return ensures flexible installation. The integrated desuperheater further boosts efficiency by providing additional hot water, making it a cost-effective and sustainable solution for home comfort.
Features:
- Qualifies for federal tax credit, and other incentives
- Highest energy efficiency in its class
- Safety high and low pressure switches
- Quiet operation
- Full featured sinusoidal eon motor control technology
- Insulated sloped stainless steel drain pan
- Advanced unit control board with diagnostic LEDs
- Double O-ring water connections
- Easy service access
- Optional domestic water pre-heating
- Made in the USA
- 10 year compressor warranty
Manuals
Manuals:
- GCHP Customer Brochure
- GCHP Desuperheater Manual
- GCHP Installation Manual
- GCHP Specification Manual
- GCHP Warranty Sheet
Specifications
Specifications:
| Dimensions | 44" H x 32" D x 25.75" W |
| AHRI Certified | Yes |
| ASHRAE Compliant | No |
| Base Warranty | 5 year limited parts warranty |
| Blower Motor Hp | 3/4 |
| Blower Motor Type | Axial Flux (No Shaft) BLA |
| Color | Gray |
|
Color Family
|
Gray |
|
Compressor Motor Type
|
Scroll |
|
Contains Aerosol
|
Yes |
|
Contains Chemicals
|
Yes |
|
Contains Compressed Gas
|
Yes |
| Contains Electronics | Yes |
| Cooling Capacity | 24000 |
| COP 47 | 4.1-5.2 |
| COP 47 Part Load | 4.5-5.3 |
| Cycle | 60 |
| EER | 21.3-28.8 |
| EER Part Load | 27.6-32.7 |
| Energy Star Certified | Yes |
| Energy Star Compliant | Yes |
| ETL Certified | No |
| ETL Listed | Yes |
| Filter Size | 28x30 |
| Filter Type | Replaceable |
| Freight Class | 85 |
| Has Batteries | No |
| Heating Capacity | 24000 |
| LEED Certified | No |
| Max Coverage Area | 1000 |
| Max Fuse Breaker | 34.0(W/O Desupe |
| Min Circuit Ampacity | 21.9 |
| Net Weight | 290 |
| Phase | 1 |
| Proposition 65 Warning | Yes |
| Refrigerant Type | R-410A |
| Registered Warranty | 10 year registered parts limited warranty & 10 year compressor warranty |
| Restricted States | No |
| Stage | Two-Stage |
| Tonnage | 2 |
| UL Listed | No |
| UL Reconized | No |
| Voltage | 230 |
