Specifically designed to be mobile and powerful, the Whynter ARC-148MS portable air conditioner can be easily setup in almost any indoor location and is often required in data closets / server rooms, bedrooms, classrooms, garages / workshops and other high-cooling demand settings.

Superior cooling operation
This ARC-148MS portable air conditioner provides a powerfu 14,000 BTU cooling output while maintaining a compact and portable profile.

Hassle-free operation
This unit features advanced self-evaporating technology, which uses and recycles moisture collected during the cooling process to produce cool air and minimize condensate build-up. It also features an auto-restart function which it automatically restarts on the previous settings after power outage. Additionally, the unit can also be programmed with a 24hr timer to activate or shut-off at preset times.

Cleaner and fresher air
This unit also features a separate dehumidifying mode that enables it to be used as a room dehumidifier as needed. A 3M© Filter and SilverShield washable pre-filter are equipped standard on this air conditioner to help keep the cooled air cleaner and fresher.

Useful features
Equipped with a remote control that can easily control the speed, temperature, timer and dehumidifier settings even from a distance, the Whynter ARC-148MS also comes with rolling casters that will allow you to move the portable air conditioner room to room.

Its programmable features, operating modes, and versatile design makes this unit a great option for keeping rooms up to 450 square feet cool and comfortable (ambient temperature and humidity may influence optimum performance).

FEATURES

● 14,000 BTU cooling capacity
● Sleek and modern all white design
● Self-Evaporative System – exhausts most or all condensate under average ambient conditions
● ECO-FRIENDLY CFC free GREEN R-410A refrigerant
● Lead free RoHS compliant components
● Four operational modes: Auto, Air conditioner, Fan or Dehumidifier
● Remote control with full functionality
● LCDI (Leakage-Current Detection and Interruption) plug
● Dehumidifying Capacity: 71 Pts / day
● Drain Methods: Continuous and Manual
● Upper and lower direct drain option for continuous operation without excess condensate accumulation
● 3 speed fan with directional air discharge louver
● 3M© Filter and SilverShield washable pre-filter
Adjustable digital thermostat control range from 62° – 88°F
● Casters for easy mobility
● 24 hour programmable timer
● Noise level (dBA): <55
● Auto restart after power outage
● Extendable exhaust hose (up to 59″)
● Upgraded Plastic window kit included
● Window kit length: Max. 48″
● Refrigerant: R-410A
● Air Flow (at high speed): 497m3/h / 292CFM
● Maximum power consumption: 1580W/ 11.9A
● Power supply: 115 V / 60Hz
● Unit dimensions: 18.5″ W x 15.75″ D x 30.25″ H
● Package dimensions: 21” W x 18″ D x 35″ H
● Net weight: 73 lbs
● Gross weight: 82 lbs
● UL listed
● UPC 850956003699

SPECIFICATION

ASHRAE BTU	14,000 BTU
Color	White
Coverage Sq. Ft.	500 sq. ft.
Dehumidifying Capacity	71 pints/ day
Exhaust Hose Length	Max. 59"
Fan Speed	3 speed
Filter Type	3M© Filter and SilverShield washable pre-filter
Heat Mode	No
Hose System	Single Hose
Louver Type	3-way oscillating
Maximum Power Consumption	1580W/ 11.9A
Noise level (dBA)	< 55
Pump Feature	No
Refrigerant	R-410A
Replacement Filter	3M Antimicrobial: ARC-FIL-3M-TYPE-M
Replacement Hose	ARC-EH-TYPE-M
Replacement Window Kit	ARC-WK-TYPEM2
SACC BTU	8,400 BTU
Storage Bag	N/A
Temperature Range	62°F – 88°F
Unit Dimensions	18.5" W x 15.75" D x 30.25" H
Upper Gravity Drain Port	Yes
Window Kit Length	Max. 48"

WARRANTY

*This unit comes with one year warranty and three year warranty on the compressor.

MANUAL

USER MANUAL
