MRCOOL Universal Series 24K-36K BTU Condenser MDUCO18024036
MRCOOL Universal Series 24,000-36,000 BTU 2-3 Ton DC Inverter Initary Cooling Only Condenser MDUCO18024036
Universal Series DC Inverter Cooling Only Condenser 2-3 Ton up to 20 SEER R410A 24,000-36,000 BTU 208-230V/1Ph/60Hz
The MRCOOL Universal Series 24,000-36,000 BTU 2-3 Ton DC Inverter Initary Cooling Only Condenser MDUCO18024036 offers up to 20 SEER efficiency, ensuring high-performance cooling with energy savings. Designed for a capacity range of 24,000-36,000 BTU and operating on 208-230V/1Ph/60Hz, it delivers effective cooling for medium-sized spaces. The advanced DC Inverter technology provides precise temperature control and reduced energy costs, making it a top choice for reliable and cost-efficient cooling solutions.
Features:
- Up to 20 SEER in 2 Ton Mode, Up to 18 SEER in 3 Ton Mode
- Compatible with any third party air handler and thermostat including the MRCOOL® Universal WiFi Thermostat or WiFi/Nest
- Low Ambient Cooling Down to 39.2 Degrees F
- Condensers Can Be Field Converted to smaller size using Dip Switch Setting
- AHRI Certified & ETL listed
- Slim Design
- Quiet 55-58dB(a) Operation
- Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion
- Multiple Connection Types: Pre-Charged No-Vac® Quick Connect® Line Set, Sweat Braze Connection, or Flare Connection
- 10 Year Registered Limited Warranty
Manuals
Manuals:
Specifications
Specifications:
| Product Dimensions | 37"W x 18-1/8"D x 32-1/4"H |
| Product Weight | 185.2 lbs |
| SEER |
20 in 2 Ton Mode 18 in 3 Ton Mode |
| EER |
12.5 in 2 Ton Mode 12.2 in 3 Ton mode |
| CFM |
3,000 in 3 Ton Mode 34,70 in 4 Ton Mode |
| Tonnage | 2-3 Ton |
| Cooling Capacity | 24,000, 36,000 BTU |
| Electrical Requirements | Requires a minimum of 208V-230V/60HZ/24A-35A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 35 A |
| Min Circuit Ampacity | 24 A |
| Color | Gray |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 118.24 oz |
| Decibel Rating | 55-57 dBA |
| Liquid Line Size | 3/8 in |
| Suction Line Size | 3/4in |
| Certifications | ETL AHRI |
| Warranty | 10 Year Limited Warranty |
