MRCOOL Universal 24K- 36K BTU Heat Pump Condenser MDUO18024036
MRCOOL Universal Series DC Inverter24K- 36K BTU 2-3 Ton, Heat Pump Condenser MDUO18024036
This product is no longer available, Our sales professionals can help you in finding something similar that matches your style, space, and budget. Feel free to contact us today at +1-800-583-0045 or email us at [email protected]
The MRCOOL Universal Series DC Inverter 24K-36K BTU 2-3 Ton Heat Pump Condenser MDUO18024036 is an excellent choice due to its high efficiency, offering up to 20 SEER with R410A refrigerant. Operating on 208-230V/1Ph/60Hz, it supports a broad BTU range, making it versatile for different space sizes. The DC Inverter technology ensures enhanced energy savings and precise temperature control, providing reliable heating and cooling performance while minimizing energy costs.
Features:
- Up to 20 SEER
- Ultra Wide Operating Temperature Range
- Gas Furnace Not Required
- Slim design allows more storage for warehouse inventory
- Compatible with any third party air handler and thermostat including WiFi/Nest
- Ideal for zero lot line homes, strict sound restriction, conventional installations, and unit replacements
- Rapid cooling and heating
- Internal Fan Blade Creates Low Noise
- Maximum savings while running
- Factory Charged
- ETL and AHRI certified
Manuals
Manuals:
- User Manual
- Product Brochure
- Performance Specifications
- Service Manual
- Warranty Document
- Accessory Manual
- AHRI Certification
- Energy Guide
Specifications
Specifications:
| Product Dimensions | 37"W x 18-1/8"D x 32-1/4"H |
| Product Weight | 217.2 lbs |
| SEER | up to 20 |
| Max SEER | 20 |
| EER | 11 |
| HSPF | 10 |
| CFM | 3470 |
| Tonnage | 2-3 Ton |
| Cooling Capacity | 36,000 BTU |
| Heating Capacity | 36,000 BTU |
| Electrical Requirements | Requires a minimum of 208V-230V/60HZ/24A-35A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 35 A |
| Min Circuit Ampacity | 24 A |
| Color | Gray |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 148.8 oz |
| Decibel Rating | 57 dBA |
| Inverter | DC |
| Min Ambient Cool | 5F - 129.2F |
| Min Ambient Heat | -22F - 75.2F |
| Lineset Included | No |
| Line Set Length | 15ft, 25ft, 35ft, 50ft |
| Max Lineset Length | 164 FT / 5 |
| Lineset Fitting Type | Pre-Flared/Sweat & Quick Connect |
| Liquid Line Size | 3/8 in |
| Suction Line Size | 3/4 |
| Compressor Motor Type | Inverter Rotary |
| Condenser Fan Motor Type | Direct Drive |
| Condenser Fan Motor RPM | 820 |
| Metering Device | EEV |
| Auxiliary Heater Available | Yes |
| Certifications | ETL Energy Star AHRI |
| Warranty |
10 Year Registered Limited Warranty 5 Years Parts |
| Restricted States | No |
