MRCOOL Signature 24K BTU, 2 Ton, 15 SEER, Split System Heat Pump Condenser MHP15024A
MRCOOL Signature 24K BTU, 2 Ton, 15 SEER, Split System Heat Pump Condenser MHP15024A
2 Ton 24,000 BTU Split System Heat Pump
The MRCOOL 15 SEER Heat Pump Split System works diligently to make your home a comfortable space. This product gives you total energy efficiency with it's enhanced tube-and-fin coil design, allowing you to get more bang for your buck. You can have peace-of-mind with this product due to its affordability, quality, efficiency, and comfort. Look no further for your family's next home central heating and air system.
Features
- Louvered construction with baked polyester finish over galvanized steel to withstand bad weather
- Raised coil to prevent debris blockage
- CoolGuard advanced corrosion resistant coil
- 4-screw louver panels, corner-mounted controlsand 45-degree offset valves for easy service.
- Enhanced tube-and-fin coil design featuring high efficiency heat transfer technology
- Thread-on pressure switches for simple, quick replacement
- Charged for 15 feet of line set
- Heavy-duty compressor sound blanket forquiet operation
- Internally protected against high temperature motor overload conditions
- Ships with filter drier
- All units ETL and ETLC approved and AHRI Certified
- 10 year registered parts warranty
Manuals
Manuals:
| Brochure |
| Install Manual |
| Specs |
| Warranty Doc |
Specifications
Specifications:
|
Dimensions |
28.25" D x 37" H x 28.25" W |
|
SEER |
15 |
|
Max SEER |
14-15 |
|
EER |
11.5 |
|
COP 47 |
3.4 |
|
COP 47 Part Load |
2.4 |
|
HSPF |
8.2-8.5 |
|
CFM |
850-875 |
|
Tonnage |
2 |
|
Cooling Capacity |
23400-24000 |
|
Heating Capacity |
21000-21600 |
|
Voltage |
208-230 |
|
Phase |
1 |
|
Cycle |
60 |
|
Stage |
Single |
|
Max Fuse Breaker |
30 |
|
Min Circuit Ampacity |
17.9 |
|
Color |
Gray |
|
Color Family |
Gray |
|
Rated Load |
13.5 |
|
Max Coverage Area |
1000 |
|
Refrigerant Type |
R-410A |
|
Refrigerant Volume |
94 |
|
Decibel Rating |
76 |
|
Inverter |
No |
|
Min Ambient Cool |
55 |
|
Lineset Included |
No |
|
Line Set Length |
15ft, 25ft, 35ft, 50ft |
|
Max Lineset Length |
50ft |
|
Lineset Fitting Type |
Sweat |
|
Liquid Line Size |
3/8 in |
|
Suction Line Size |
3/4 |
|
Compressor Motor Type |
Scroll |
|
Condenser Fan Motor Type |
Direct Drive |
|
Condenser Fan Motor HP |
1/6 |
|
Condenser Fan Motor RPM |
825 |
|
Metering Device |
TXV |
|
Auxiliary Heater Included |
No |
|
Auxiliary Heater Available |
Yes |
|
Auxiliary Heater Sizes |
7.5kw, 10kw |
|
UL Reconized |
No |
|
UL Listed |
No |
|
ETL Listed |
Yes |
|
ETL Certified |
No |
|
LEED Certified |
No |
|
Energy Star Compliant |
No |
|
Energy Star Certified |
No |
|
AHRI Certified |
Yes |
|
Registered Warranty |
Registered 10 Year Parts Warranty |
|
Base Warranty |
5 Year Parts Warranty |
|
Registered Parts Warranty |
Registered 10 Year Parts Warranty |
|
Base Parts Warranty |
5 Year Parts Warranty |
|
Has Batteries |
No |
|
Contains Electronics |
Yes |
|
Contains Chemicals |
Yes |
|
Contains Aerosol |
Yes |
|
Contains Compressed GAS |
Yes |
|
Proposition 65 Warning |
Yes |
|
Restricted States |
No |
|
Net Weight |
177 |
|
Gross Depth |
30.50 in |
|
Gross Height |
37.50 in |
|
Gross Width |
31 in |
