MRCOOL Hyper Heat 24K BTU Air Handler CENTRAL-24-HP-MUAH230A00
MRCOOL Hyper Heat Central Ducted 24K BTU 2 Ton Air Handler CENTRAL-24-HP-MUAH230A00
Why choose the MRCOOL Hyper Heat Central Ducted 24K BTU Air Handler, CENTRAL-24-HP-MUAH230A00?
The MRCOOL Hyper Heat Central Ducted 24K BTU Air Handler offers efficient and reliable heating and cooling for smaller to medium-sized spaces. Its advanced design ensures consistent comfort and energy savings, making it ideal for residential and light commercial applications. Buy from Wine Coolers Empire for high-quality HVAC solutions and excellent service.
Compatible Paired Unit:
MRCOOL Hyper Heat Central Ducted Air Handler Features:
- Energy Efficient. Up to 17.4 SEER2
- Multi-Position Installation. Can be installed upflow, downflow, horizontal left or horizontal right.
-
Mobile Home Friendly. Can accommodate the high static requirements for manufactured and modular homes.
- Worry-Free Performance. 10-year Warranty on Parts, Labor, and Compressor
Manuals
MRCOOL Hyper Heat Central Ducted Air Handler Manuals:
Specifications
MRCOOL Hyper Heat Central Ducted Air Handler Specifications:
| Air Handler Dimensions | 21.02"W x 17.52"D x 45"H |
| Air Handler Weight | 105.60 lbs |
| CFM | 823.53/758.82/694.12/629.41 |
| Cooling Capacity | 24,000 BTU |
| Heating Capacity | 24,000 BTU |
| Voltage | Requires a minimum of 208-230V/60HZ/4 to 15A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 15 |
| Min Circuit Ampacity | 4 |
| Coverage Area | 1,000 square feet |
| Refrigerant Type | R410A |
| Decibel Rating | 33 to 39 |
| Air Flow Direction | Upflow, Downflow, Horizontal Left, Horizontal Right |
| Number of Speeds | 4 |
| Room Temperature | Cool: 61°F to 90°F Heat: 32°F to 86°F Dry: 50°F to 90°F |
| Line set Included | No |
| Max Line Set Length | 164.04 |
| Liquid Line Size | 3/8in |
| Suction Line Size | 3/4in |
| Auxiliary Heater Included | No |
| Auxiliary Heater Available | Yes - 5kW, 8kW, 10kW, 15kW |
| Certificates | AHRI |
| Warranty | 10 years Parts and Labor |
| Propositon 65 Warning | Yes |
MRCOOL Hyper Heat Central Ducted 24K BTU 2 Ton Air Handler CENTRAL-24-HP-MUAH230A00
Why choose the MRCOOL Hyper Heat Central Ducted 24K BTU Air Handler, CENTRAL-24-HP-MUAH230A00?
The MRCOOL Hyper Heat Central Ducted 24K BTU Air Handler offers efficient and reliable heating and cooling for smaller to medium-sized spaces. Its advanced design ensures consistent comfort and energy savings, making it ideal for residential and light commercial applications. Buy from Wine Coolers Empire for high-quality HVAC solutions and excellent service.
Compatible Paired Unit:
MRCOOL Hyper Heat Central Ducted Air Handler Features:
- Energy Efficient. Up to 17.4 SEER2
- Multi-Position Installation. Can be installed upflow, downflow, horizontal left or horizontal right.
-
Mobile Home Friendly. Can accommodate the high static requirements for manufactured and modular homes.
- Worry-Free Performance. 10-year Warranty on Parts, Labor, and Compressor
Manuals
MRCOOL Hyper Heat Central Ducted Air Handler Manuals:
Specifications
MRCOOL Hyper Heat Central Ducted Air Handler Specifications:
| Air Handler Dimensions | 21.02"W x 17.52"D x 45"H |
| Air Handler Weight | 105.60 lbs |
| CFM | 823.53/758.82/694.12/629.41 |
| Cooling Capacity | 24,000 BTU |
| Heating Capacity | 24,000 BTU |
| Voltage | Requires a minimum of 208-230V/60HZ/4 to 15A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 15 |
| Min Circuit Ampacity | 4 |
| Coverage Area | 1,000 square feet |
| Refrigerant Type | R410A |
| Decibel Rating | 33 to 39 |
| Air Flow Direction | Upflow, Downflow, Horizontal Left, Horizontal Right |
| Number of Speeds | 4 |
| Room Temperature | Cool: 61°F to 90°F Heat: 32°F to 86°F Dry: 50°F to 90°F |
| Line set Included | No |
| Max Line Set Length | 164.04 |
| Liquid Line Size | 3/8in |
| Suction Line Size | 3/4in |
| Auxiliary Heater Included | No |
| Auxiliary Heater Available | Yes - 5kW, 8kW, 10kW, 15kW |
| Certificates | AHRI |
| Warranty | 10 years Parts and Labor |
| Propositon 65 Warning | Yes |
$483.24
Original: $1,610.80
-70%MRCOOL Hyper Heat 24K BTU Air Handler CENTRAL-24-HP-MUAH230A00—
$1,610.80
$483.24Description
