MRCOOL DIY Multi-Zone 3-Zone 27K BTU Condenser DIY-MULTI3-27HP230C
MRCOOL DIY 4th Gen Multi-Zone 27K BTU 3-Zone Condenser DIY-MULTI3-27HP230C
Low Stock – Call for Availability
This item is currently in low stock. For the latest availability or assistance, contact our sales team at +1-800-583-0045 or email us at [email protected]
Why is the MRCOOL DIY 4th Gen Multi-Zone 27K BTU 3-Zone Condenser DIY-MULTI3-27HP230C a great choice for efficient multi-zone temperature management?
The MRCOOL DIY 4th Gen Multi-Zone 27K BTU 3-Zone Condenser DIY-MULTI3-27HP230C is an excellent choice for efficient multi-zone temperature management, offering 27K BTU capacity to control three separate zones. Its ductless split design ensures flexible installation and precise climate control without the need for ductwork. The DIY installation feature simplifies setup and reduces labor costs, while its high energy efficiency helps lower utility bills. This system is ideal for homeowners seeking customizable, cost-effective, and efficient climate management across multiple areas.
Features:
- Up to 22 SEER
- Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long-term corrosion
- Energy-Efficient DC Inverter
- R-410A environmentally friendly refrigerant
- Standard 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty
Manuals
Manuals:
- Installation Manual
- Product Brochure
- Performance Specifications
- Warranty
- Energy Guide
- AHRI Certificate
Specifications
Specifications:
| Product Dimensions | 37.24"W x 16.14"D x 31.89"H |
| Product Weight | 139.99 lbs |
| SEER2 | 22 |
| EER2 | 12 |
| HSPF2 | 9.5 |
| SEER | 22 |
| EER | 12 |
| HSPF | hspf4/hspf5 : 10.3/8.2 |
| CFM | 2129.41 |
| Cooling Capacity | 27,000 BTU |
| Heating Capacity | 27,000 BTU |
| Voltage |
Requires a minimum of 208V-230V/60HZ/26-40A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker | 40 A |
| Min Circuit Ampacity | 26 A |
| Color | White |
| Zone Capacity | 3 |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 91.71 oz |
| Decibel Rating | 61 dBA |
| Inverter | Yes |
| Min Ambient Cool | 5°F ~ 122°F |
| Min Ambient Heat | -13°F ~ 75.2°F |
| Max Lineset Length | 172.5 ft TOTAL |
| Liquid Line Size | 1/4in |
| Suction Line Size | 3/8in |
| Compressor Motor Type | Twin - Rotary |
| Condenser Fan Motor RPM | 1050/900/850 |
| Wifi Compatibility | Yes |
| App Compatibility | Yes |
| Compatible with | IOS Android |
| Warranty | 5-year Parts/7-year Compressor |
