MRCOOL DIY 4th Generation Energy Star 12K BTU 1 Ton Ductless Mini-Split Heat Pump Complete System DIY-12-HP-WM-115C25

This product is no longer available, Our sales professionals can help you in finding something similar that matches your style, space, and budget. Feel free to contact us today at +1-800-583-0045 or email us at [email protected]

The MRCOOL DIY 4th Gen E STAR 12K BTU 1 Ton Ductless Mini-Split Heat Pump DIY-12-HP-WM-115C25 is perfect for small spaces due to its compact size and 12K BTU capacity. Its easy DIY installation saves on professional labor costs, while its high SEER rating ensures exceptional energy efficiency. This system provides effective heating and cooling, making it a cost-effective and convenient choice for homeowners seeking reliable and efficient climate control in limited spaces.

Features:

• Up to 22.50 SEER2
• Gold Fin® condenser: corrosion-resistant coastal living - don't worry, our condenser is built to resist long term corrosion
• Variable-speed DC inverter compressor technology cuts operating costs
• R-410A environmentally friendly refrigerant
• Standard 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty

Manuals

Manuals:

• Installation Manual
• Product Brochure
• Performance Specifications
• Service Manual
• Remote Control
• Warranty
• Energy Guide
• AHRI Certificate

Specifications

Specifications:

Condenser Dimensions	30.12"W x 11.93"D x 21.85"H
Condenser Weight	65.70 lbs
Air Handler Dimensions	31.57"W x 7.44"D x 11.69"H
Air Handler Weight	24.03 lbs
SEER2	22.50
EER2	12.50
SEER	22
EER	12.5
COP 47	3.36
HSPF2	9.00
HSPF	hspf4/hspf5 : 11.5/9
CFM	305.88/211.76/147.06
Cooling Capacity	12,000 BTU
Heating Capacity	12,000 BTU
Voltage	Requires a minimum of 115V/60HZ/19-25A (please check your home meets this electrical requirement prior to purchase)
Phase	1
Cycle	60 Hz
Max Fuse Breaker	25 A
Min Circuit Ampacity	19 A
Color	White
Rate Load	0.53 A
Max Coverage Area	Up to 500 sqft
Zone Capacity	1
Refrigerant Type	R-410A
Refrigerant Volume	38.10 oz
Decibel Rating	37/31/23.5
Decibel Rating Low	23.5 dBA
Decibel Rating High	37 dBA
Oscillation	4-W
Inverter	Yes
Min Ambient Cool	-13F - 122F
Min Ambient Heat	-13F - 75F
Line Set Length	25ft
Max Lineset Length	82.02 ft
Liquid Line Size	1/4 in
Suction Line Size	1/2 in
Compressor Motor Type	Rotary
Condenser Fan Motor RPM	850/600
Blower Motor RPM	1100/850/700
Auxiliary Heater Available	No
Modes	Fan Only Quiet Mode Auto Cool
Wifi Compatibility	Yes
App Compatibility	Yes
Compatible with	IOS Android
Includes	Remote Batteries
Certifications	UL Listed Energy Star AHRI
Warranty	5-year Parts/7-year Compressor
Restricted States	GU;PR;VI
