Bertazzoni Master Series 48" 6 Aluminum Burners Bianco Matt Freestanding Propane Gas Range With 7.1 Cu.Ft. Double Oven and Electric Griddle MAS486GGASBIV-LP
Bertazzoni Master Series 48" 6 Aluminum Burners Bianco Matt Freestanding Propane Gas Range With 7.1 Cu.Ft. Double Oven and Electric Griddle MAS486GGASBIV-LP Product Details
48" Master Series range - Gas Oven - 6 aluminum burners + griddle
Bertazzoni's new ranges, crafted in Italy, seamlessly blend into stylish kitchen suites, promising top-notch performance. Their high-efficiency maintop features 6 burners, including 2 powerful 19,000 BTU burners, and an electric griddle. The 4.7 cubic feet main oven cavity, with dual convection fans, ensures even baking and roasting on 7 shelf levels. An extra-wide gas broiler and a 2.4 cubic feet auxiliary oven offer versatility, both with soft-motion doors. Optional Collezione Metalli décor sets personalize the range, refrigerators, and dishwashers with satin gold and black nickel accents.Features
- Available in Stainless Steel, Nero Matt (Black), and Bianco Matt (White) finishes.
- Factory-converted to LP gas
Manuals
Manuals:
Specifications
Specifications:
Worktop
| Brand | Bertazzoni |
| Item Number | MAS486GGASBIV + CONVERSION |
| Finish | Bianco Matt |
| Size | 48 in |
| Cooking Zones | 7 |
| Number of Gas Zones | 6 burners |
| Griddle Zones | electric |
| Worktop Type | electric / gas |
| Worktop Design | stainless steel squared |
| Worktop Controls | knobs |
| Knobs | solid metal |
| Burner Type | aluminum |
| Grates | cast iron |
| Continous Grating | yes |
| Thermocouple Safety Device | yes |
| One-hand Ignition | yes |
| Backguard | yes |
| Simmer Ring | yes |
Cooking Zones
| Power Burner | 1300 BTU/h - 19 000 BTU/h (2) |
| Rapid Burner |
2500 BTU/h - 10 400 BTU/h (1) |
| Medium Burner | 1500 BTU/h - 5900 BTU/h (2) |
| Simmer Burner | 750 BTU/h - 3500 BTU/h (1) |
| Griddle Power | 1100 W |
Oven Cavity
| Oven Configuration | double |
| Oven Fuel | gas |
| Oven Convection System | dual horizontal fans |
| Main Oven Type | fan assisted gas |
| Main Oven Broiler Type | gas |
| Main Oven Functions |
bake/ broil/ convection bake |
| Main Oven Volume | 4.7 ft³ |
| Auxiliary Oven Type | gas conventional |
| Auxiliary Oven Functions | bake |
| Auxiliary Oven Volume | 2.4 ft³ |
| Oven Controls | knobs / thermometer |
| Inner Oven Door | triple |
| Removable Inner Glass | yes |
| Cooling Fan | yes |
| Oven Levels | 7 |
| Door Hinges | soft-motion |
| Wire-Shelves |
2 each cavity |
| Tray | 1 baking tray with grill trivet |
| Grill Trivet for Tray | yes |
| Oven Lights | double lateral |
Bottom
| Legs | stainless steel |
Technical Specifications
| Absorbed Current (A) | 10 A with dedicated circuit |
| Electrical Supply | 110V 60 Hz - 1200W |
